3axles Flatbed Rear Dump Semi Trailer
-
Leading sales products:
Powder material transport semi-trailer, concrete mixing transport truck, low flatbed semi-trailer, fence semi-trailer, box type transport semi-trailer, warehouse rack transport semi-trailer, dump truck, dump semi-trailer, low flatbed dump semi-trailer, container transport semi-trailer, oil tank truck, etc.
Product Introduction
HYUAN produces durable Tipping Flatbed Trailer for standard 20ft 40ft Containers, and especially for Africa market. The container trailers widely used in transportation industry. Especially to load the 2 * 20'', 40'' containers.
And HYUAN TIPPER SEMI TRAILER adopt advanced design concept. After fully understanding and analysing the transportation environment in different countries. Different axle and suspension settings to accommodate different operations. The trailers can be customized.
Product specification
|
Specification |
|
|
1. Dimension |
7200 x 2490 x 1620 mm (Two Axles, LxWxH) |
| 12250 x 2490 x 1530 mm (Three Axles, LxWxH) | |
|
2. Tare weight |
4300 kg (Two Axles); 7600 kg (Three Axles) |
|
3. Payload |
30 tons |
|
4. Twist lock |
4/12 units |
|
5. Function |
Load 1x20'/40' container and self-unloading |
|
6. Hydraulic system |
Chinese brand |
|
Standard Configuration |
|
|
1. Axle |
13 ton Fuwa brand, 150x150, 2/3 units |
|
2. Suspension |
Mechanical suspension |
|
3. King pin |
2", bolt on type |
|
4. Landing gear |
28 ton, two speeds |
|
5. Tire |
11R22.5, 8/12 units |
|
6. Rim |
8.25-22.5, 8/12 units |
|
7. Braking system |
Gladhand valve, Wabco relay valve, 30/30 double brake chambers on rear axle, 30 single chambers on other axles |
|
8. Electrical system |
Dual circuit, 7-way split pin receptacle plug, LED light |
|
9. ABS |
None |
|
10. Painting |
Blasting sand before painting, one coat primer and two coat finish painting, colour supplied by customer |
|
11. Mudguard |
Plastic or steel |
|
12. Others |
1 tool box, 1 wheel carrier, excluding spare wheel |
|
Optional Configurations |
|
|
1. Air suspension |
Firestone, Goodyear or Chinese brand |
|
2. Lift axle system |
|
|
3. ABS system |
Wabco or Chinese brand |
|
4. Axle |
BPW 12 ton |
|
5. Hydraulic system |
Germany HYVA |
Product feature and application
Tractor Hydraulic Dump Trailer----According your needs,you can choose BPW axle or FUWA axle or other brand axle ,air suspension or leaf spring suspension.
The main parts are processed by advanced equipment, and the longitudinal beams are fully automatic submerged arc welding.
Product qualification
The products are excellent and have passed many national indicators, I S O 9 0 0 0 and C C C, and won many honors. Has been awarded the title of "meritorious enterprise", "advanced enterprise" and "star enterprise" by the county Party committee and the county government.
Deliver,shipping and serving
Packing detail: Wax, nude, can be carried by bulk carriers or ro-ro ship.
Delivery detail: Within 30 days after receive the payment.
Our service
Email will be replied within 8 hours.
We insists on professional and warmly service.
We can provide you with better service and more competitive price.
Our company has been committed to producing all kinds of trailers for many years.
FAQ
Q1. Are you a manufacturer?
Yes, welcome to visit our factory at anytime
Q2. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q3. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
