Howo 371hp Tractor Truck
-
Leading sales products:
Powder material transport semi-trailer, concrete mixing transport truck, low flatbed semi-trailer, fence semi-trailer, box type transport semi-trailer, warehouse rack transport semi-trailer, dump truck, dump semi-trailer, low flatbed dump semi-trailer, container transport semi-trailer, oil tank truck, etc.
Product Introduction
It is suitable for various working conditions. With the smartshift of SINOTRUK, drivers can focus more on driving and surrounding traffic environment and respond in a timely manner. Help new drivers reach the level of senior drivers. The driver can still shift gears manually. Switch to the manual mode and use the control handle to select the appropriate gear. The truck with smartshift has no clutch pedal and the shift is fully automatic.
Product specification
|
Drive mode |
6x4 |
|||
|
Truck Brand |
SINOTRUK-HOWO |
|||
|
Dimension(Lx W xH)(mm) |
6800x2496x3668 |
|||
|
Approaching angle/ Departure angle(°) |
16/70 |
|||
|
Overhang(front/rear) (mm) |
1500/725 |
|||
|
Wheel base (mm) |
3200+1400 |
|||
|
Max speed(km/h) |
90, 102 |
|||
|
Curb weight(kg) |
9210 |
|||
|
Gross Vehicle Weight(kg) |
25000 |
|||
|
Engine |
Model |
WD615.47, water-cooled,four strokes, 6 cylinders in line with water cooling, turbocharged and intercooling, directly injection |
||
|
Fuel type |
Diesel |
|||
|
Horsepower |
371HP |
|||
|
Emission Standard |
Euro 2 |
|||
|
Fuel tank capacity |
400L |
|||
|
Transmission |
Model |
HW19710, 10forwards & 2reverse |
||
|
Brake system |
Service brake |
Dual circuit compressed air brake |
||
|
Parking brake |
spring energy, compressed air operating on rear wheels |
|||
|
Auxiliary brake |
engine exhaust valve brake |
|||
|
Steering system |
Model |
8198,hydraulic system with power assistance |
||
|
Front axle |
HF7 |
|||
|
Rear axle |
ST16 |
|||
|
Tyre |
295/80R22.5 or 12R22.5. 11pcs(10+1spare) |
|||
|
Clutch |
430 diaphragm spring clutch,hydraulic control air power assisted |
|||
|
Electrical system |
Battery |
2X12V/165Ah |
||
|
Alternator |
28V-1500kw |
|||
|
Starter |
7.5Kw/24V |
|||
|
Cab |
HW79 cabin, two beds, with air-condition. all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
|||
Product feature and application
Cooperate with the first-class international suppliers, according to the advanced robot full-automatic assembly line welding, to reduce the overall accuracy error to the minimum; the body strength is leading in China, and the cab can be moved back by 20 cm in a moment in the face of collision; a large number of non sharp angle design and flame-retardant materials are used; the internal design of inertia rotary seat belt and bumper anti drilling device makes the safety performance of the whole vehicle stand alone in China 。 The frame longitudinal beam made of new high-strength materials has a tensile strength of more than 820mpa; the first disk type twitcher in China, 430 pull type diaphragm spring clutch, the new technology of optimized design, the front axle and HW12, 16 series single and double axles are mature and reliable, forming a vehicle matching with excellent performance.
Product qualification
The products are excellent and have passed many national indicators, I S O 9 0 0 0 and C C C, and won many honors. Has been awarded the title of "meritorious enterprise", "advanced enterprise" and "star enterprise" by the county Party committee and the county government.
Deliver,shipping and serving
Roll on roll off (RORO) ship
It's the specialized ship to transport cars and trucks, which has power wheel, it's the best way of truck transportation.
Bulk carrier ship
It's the specialized ship to transport grain, coal, ore, salt, cement ,etc, dry and bulk goods, can also used to transport trucks,price is cheap, but the truck always be put on the deck, sea water will damage the truck painting.
Container ship
It's well-known shipping way, and also the highest cost among these three ways. Few sea port only container ship can arrive, so sometimes, we have to use container ship.
Our services
Reply your inquiry in 12 working hours;
Experienced staffs answer all your questions;
Customer’s design is available for certain products(OEM);
Spare parts for all types of engine machinery with reasonable price;
