Function

Carry40ft/2x20ft container or other stuff

Overall Dimension

(Lx W x H)(mm)

12500*2500*1550

Tare Weight(KG)

6550

Loading Weight( KG)

40000

Total Weight(KG)

50000

Axle Brand

13TON Fuwa axles brand

Axle Number

3

Wheelbase(mm)

2300+1310+1310

Suspension system

Common Mechanical suspension

Steel Spring

10/10/10 leaf spring suspension

The material of Main beam

The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8mm.

Container Twist Locker

12pcs container lock

Tire Type and quantity

12R22.5 tyres,  triangle brand

Spare Wheel Bracket

1 pieces

Tool Box

1 Standard

Landing Gear

Chinese standard  28ton

Brake system

Dual Line braking system

Brake air chamber

Two double and two single chamber

Electrical system

1. Voltage: 24v   2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core standard Cable.

Side Guard

According to customer’s requirement

Painting

Color as customer’s requirement

Packing

NUDE, Polish with wax before shipping
