Dimension

12000mm*2490mm*3990mm( Exact size depends on the final design)

Tare weight kg

About 11800KGS-13000KGS

Tank capacity( CBM )

30cbm-60cbm（Volume optional）

Shape

Optional(v or w shape)

Compartments

One or two compartment

Tanker Body Material

5mm or 6mm/Q235 carbon steel

End Plate

5mm or 6mm/Q235 carbon steel

Rim

8.00-20/8.5-20/8.8-20/9.0-22.5  China Brand

Tire

12R22.5/11R22.5/13R22.5/11.00R20/12.00R20( brand can be Optional)

Engine

Weichai 4105 Engine

Manhole Cover

500mm carbon steel or aluminum alloy manhole

Bottom Valve

3''/ 4” disc valve

Discharging Valve

Diameter is 3 or 4 inch

Discharging Pipe

4” rubber hose, 2 pcs,  6m/each

Air compressor

10 m3,12m3

Diesel Engine

Weichai Huafeng, Tianhe 4102/4105

Main Beam

Welding design or Special design, connected by bolts and nuts.

Material:Q345 carbon steel

Height 500mm,
Upper Thickness 14~18mm,
Middle Thickness 8~12mm,
Down Thickness 16~20mm

Axle

2 or 3 axles, BPW/FUWA brand（Optional）

Landing Gear

JOST(D200T)or China brand 28T(two speed)

Brake System

WABCO Valve with big chamber

King Pin

JOST 2.00 or 3.5 inch bolt-in king pin

Suspension

Mechanical suspension or Air suspension

Leaf Spring

90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12

Rear ladder

Dismountable

Lights

Turning Light, Side Marker Light, Tail Light

Voltage

24V

Receptacle

7 ways (7 wire harness)

Painting

Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint

ABS

Optional

Accessories

One standard tool box

Shipping Terms

By Bulk Cargo Carrier, RORO or 40HQ Containers
