Used HOWO Dump Truck
-
Leading sales products:
Powder material transport semi-trailer, concrete mixing transport truck, low flatbed semi-trailer, fence semi-trailer, box type transport semi-trailer, warehouse rack transport semi-trailer, dump truck, dump semi-trailer, low flatbed dump semi-trailer, container transport semi-trailer, oil tank truck, etc.
Product Introduction
A dump truck is a truck used to convey loose materials like sands, pebbles, soils, building materials, coals, ores, crops, farm products, etc. A dump truck is usually installed with a hydraulic motivated open-box bed hinged at the rear. The front of this open-box can be lifted up so that the materials are discharged on the ground behind the truck.
Product specification
|
SPECIFICATION |
||||
|
Dimension(Lx W xH)(unloaded)(mm) |
9470×2496×3450 |
|||
|
Cargo body size (LxWxH) (mm) |
6500x2300x1500 Sand body,Front lifting,Bottom 8 mm, Side 6 mm |
|||
|
Approaching angle/Departure angle(°) |
19/20 |
|||
|
Overhang(front/rear) (mm) |
1500/2295 |
|||
|
Wheel base (mm) |
4625+1350 |
|||
|
Max speed(km/h) |
78 |
|||
|
Curb weight(kg) |
12500 |
|||
|
Engine(Steyr technology, made in China) |
Model |
WD615.47,water-cooled,four strokes, 6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection |
||
|
Fuel type |
Diesel |
|||
|
Power, max(kw/rpm) |
371HP |
|||
|
Emission |
EUROII |
|||
|
Fuel tanker capacity(L) |
300L aluminum oil tank |
|||
|
Transmission |
Model |
HW19710, 10 speeds forward and 2 reverse |
||
|
Brake system |
Service brake |
Dual circuit compressed air brake |
||
|
Parking brake |
spring energy, compressed air operating on rear wheels |
|||
|
Steering system |
Model |
ZF8118 |
||
|
Front axle |
HF9 |
|||
|
Rear axle |
HC16 |
|||
|
Tire |
12.00R20 |
|||
|
Electrical system |
Battery |
2X12V/165Ah |
||
|
Alternator |
28V-1500kw |
|||
|
Starter |
7.5Kw/24V |
|||
Product feature and application
1) Large torque, low rotate speed, and low oil consumption
2) Compliance with EURO3/EURO4
3) Adopt to SMARTSHIFT-AMT
4) Adopt to tubeless tires, 315/80R22.5
Product qualification
The products are excellent and have passed many national indicators, I S O 9 0 0 0 and C C C, and won many honors. Has been awarded the title of "meritorious enterprise", "advanced enterprise" and "star enterprise" by the county Party committee and the county government.
Deliver,shipping and serving
1) Flatrack container
2) By bulk ship
3) By RO-Ro ship : Pirce is high but protect the trailer very well
Our service
Professional Production Team:
Experienced Sales,Provide Clients High Assembling for Fast Quality Delivery
Customize:
Professional Design Team Provide Suitable Programs and Customized,Support Local Adaptive Product
7*24H Service
7*24H Service Provide Professional Fast Response
Parts Support:
Abundant Parts Supply Provide Lasting Support for Worldwide Clients
FAQ
Q1: What kind of payment do you accept?
A: We accept T/T and L/C; Others payment is negotiable.
Q2: What's your minimum order quantity?
A: One unit
Q3: What's your delivery time?
A: 30 days after received the deposit.
Q4: What's warranty time?
A: 12 months or 30,000 km from the date of shipment whichever comes first
Q5: What's your after-sale service?
A: We provide technical support for our trucks and whole life parts supply
