Howo 6X4 Tractor Truck
-
Leading sales products:
Powder material transport semi-trailer, concrete mixing transport truck, low flatbed semi-trailer, fence semi-trailer, box type transport semi-trailer, warehouse rack transport semi-trailer, dump truck, dump semi-trailer, low flatbed dump semi-trailer, container transport semi-trailer, oil tank truck, etc.
Product Introduction
It is suitable for various working conditions. With the smartshift of SINOTRUK, drivers can focus more on driving and surrounding traffic environment and respond in a timely manner. Help new drivers reach the level of senior drivers. The driver can still shift gears manually. Switch to the manual mode and use the control handle to select the appropriate gear. The truck with smartshift has no clutch pedal and the shift is fully automatic.
Product specification
|
Drive mode |
6x4 |
|||
|
Truck Brand |
SINOTRUK-HOWO |
|||
|
Dimension(Lx W xH)(mm) |
6800x2496x3668 |
|||
|
Approaching angle/Departure angle(°) |
16/70 |
|||
|
Overhang(front/rear) (mm) |
1500/725 |
|||
|
Wheel base (mm) |
3200+1400 |
|||
|
Max speed(km/h) |
90, 102 |
|||
|
Curb weight(kg) |
9210 |
|||
|
Gross Vehicle Weight(kg) |
25000 |
|||
|
Engine
|
Model |
WD615.47, water-cooled,four strokes,6 cylinders in line with water cooling, turbocharged and intercooling, directly injection |
||
|
Fuel type |
Diesel |
|||
|
Horsepower |
371HP |
|||
|
Emission Standard |
Euro 2 |
|||
|
Fuel tank capacity |
400L |
|||
|
Transmission |
Model |
HW19710, 10forwards & 2reverse |
||
|
Brake system
|
Service brake |
Dual circuit compressed air brake |
||
|
Parking brake |
spring energy, compressed air operating on rear wheels |
|||
|
Auxiliary brake |
engine exhaust valve brake |
|||
|
Steering system |
Model |
8198,hydraulic system with power assistance |
||
|
Front axle |
HF7 |
|||
|
Rear axle |
ST16 |
|||
|
Tyre |
295/80R22.5 or 12R22.5. 11pcs(10+1spare) |
|||
|
Clutch |
430 diaphragm spring clutch,hydraulic control air power assisted |
|||
|
Electrical system |
Battery |
2X12V/165Ah |
||
|
Alternator |
28V-1500kw |
|||
|
Starter |
7.5Kw/24V |
|||
|
Cab |
HW79 cabin, two beds, with air-condition. all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
|||
Product feature and application
The driver's cab designed with the latest achievements of ergonomics is comfortable in environment, which can ensure the energy of drivers and passengers;
Wide front windshield and combined rear-view mirror eliminate blind area, with excellent vision;
Upper sleeper shall be equipped with safety protection network;
Fully adopt the latest technology upgrade of veburke ABS, add ASR + EBL + TPM on the basis of fully meeting European regulations, and ensure driving safety to the maximum extent. ASR - to avoid vehicle skidding; EBL - to ensure better distribution of braking force; TPM - to monitor tire pressure changes at any time.
Led rear tail light is adopted, with large brightness, long service life and low failure, which makes driving at night safer.
The engine EVB new braking technology is to ensure that when the vehicle is driving down the long slope road, it can effectively control the speed, increase the braking power of the whole vehicle, reduce the frequency of using the brake, and reduce the wear of the service brake and tire. The improvement of the service life and driving safety of the whole vehicle will make the driver more assured.
Fully adopt the braking mode of front disc and rear drum to effectively shorten the braking distance and ensure the driving safety.
Product qualification
The products are excellent and have passed many national indicators, I S O 9 0 0 0 and C C C, and won many honors. Has been awarded the title of "meritorious enterprise", "advanced enterprise" and "star enterprise" by the county Party committee and the county government.
Deliver,shipping and serving
Mode of transport: bulk cargo, ro-ro transport, container transport.
We can arrange the most cost-effective transportation solution according to the number of semi-trailers required by customers.
Our Service
Professional Production Team:
More Than 300 Experienced Workers,Provide Clients High Assembling for Fast Quality Delivery
Customize:
Professional Design Team Provide Suitable Programs and Customized
7*24H Service:
7*24H Service Provide Professional Fast Response
Parts Support:
Abundant Parts Supply Provide Lasting Support for Worldwide Clients
