50cbm V Shape Cement Tank Trailer
-
Leading sales products:
Powder material transport semi-trailer, concrete mixing transport truck, low flatbed semi-trailer, fence semi-trailer, box type transport semi-trailer, warehouse rack transport semi-trailer, dump truck, dump semi-trailer, low flatbed dump semi-trailer, container transport semi-trailer, oil tank truck, etc.
Product Introduction
Bulk Cement Tanker Trailer also know as cement bulker, pneumatic trailer.
Cement Bulk Tank Fly Coal ash and kinds of diameter ≤ 1mm Powder Material Storage and Transporting.
Cement Bulker Tanker Trailerimproves the loading and unloading efficiency, and reduce material loss.
Widely used in cement factories, cement warehouses，concrete batching plant and large construction sites.
Product specification
|
Trailer Model |
3 Axles Promotional 35m3 50cbm Dry Powder Silo Transport Tank Bulk Cement Bulker Tanker Trailer |
|
Overall Dimension |
11000×2500×3850mm |
|
Axle Number |
3 units |
|
Wheelbase(mm) |
8000+1310+1310 |
|
Steel Spring |
-/10/10/10 leaf spring suspension |
|
The material of main beam |
The height of the beam is 500 mm, upper plate is14mm, down plate is16mm, middle plate is 8mm |
|
Tank thickness |
5 mm, end/front 6mm |
|
Compartment |
One, With 2 manholes |
|
Tire Type and quantity |
12R22.5 tubeless tires, taitong brand 12 pieces |
|
Steel rim |
12 pieces |
|
Traction Pin |
90mm or 50mm |
|
Spare Wheel Carrier |
1 piece |
|
Tool Box |
1 standard |
|
The diesel engine |
Weichai Tianhe 4102 |
|
Air compressor |
Bohai 12 CBM/min |
|
Landing Gear |
Standard single speed 28ton |
|
Brake system |
Dual Line braking system |
|
Brake air chamber |
Six double air chamber, wabco emergency valve |
|
Electrical system |
1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) 3. One set 6-core standard Cable. |
|
Side Guard |
According to customer’s requirement |
|
Painting |
Color by customer’s requirement |
|
Packing |
Polish with wax before shipping |
Product feature and application
The bulk cement trailer is normlly used in powder cargo transportation such as cement, mineral powder, ashes, flour, and other powder with diameter less than 0.1mm.The powder is discharged by compressed air generated by the air compressor. The tanker shell is specially desgined to bear the large air pressure. The tank design helps toshorten the discharge,time and reduce the residual during unloading. As other types of the tanker trailer, there are various options for tanker size, in which 36CMB is the most preferred, the thickness of tanker is 6mm. The air compressor, powered by PTO or separated engine, adopts Honda or other brands the customer named.
Prodection details
A. Tanker workshop overview
B. Tanker body auto welding
C. Chassis welding by experienced worker
D. Production line
E. Shot blasting for rust cleaning
F. Dust-free painting
G. Finished trailer
Product qualification
The products are excellent and have passed many national indicators, I S O 9 0 0 0 and C C C, and won many honors. Has been awarded the title of "meritorious enterprise", "advanced enterprise" and "star enterprise" by the county Party committee and the county government.
Our Services
● More than 20 years professional design and production experience.
● Choose Regular manufacturers purchase materials,like Q235 baoshan.
● Use Domestic first-class production equipment.
● Famouse brand trailer parts used, like bpw/ fuwa axle, triangle/ double star/ double coin and so on tires, Air pressure test for each tanker.
● Strict quality control system ensure that each semi trailer is qualified.
Deliver,shipping and serving
Mode of transport: bulk cargo, ro-ro transport, container transport.
We can arrange the most cost-effective transportation solution according to the number of semi-trailers required by customers.
FAQ
1. Q: What kind of payment do you accept?
A: We could accept T/T and L/C normally. For other, please contact me for more information.
2. Q: What's your delivery time?
A: For our lowbed semi trailer, it takes 15-20 days after receiving advance payment. It depends on the specification.
3. Q: What's your after-sale service?
A: We have excellent after-sale service system and 24h liftetime service.
